Rexroth Hydraulic Motor A2FM10/12/16/32/45/63/80/107 For Construction Machinery

A2FM10/12/16/32/45/63/80/107 REXROTH HYDRAULIC MOTOR for Construction machinery

1, Product Overview
The A2FM series is a Rexroth axial piston motor known for its durability, high efficiency, and high power density. This series of motors is the core power component of closed-loop hydraulic systems, widely used in various demanding industrial, engineering, and marine fields.
2, Core features and advantages
1. Excellent power density:
·Adopting a compact inclined axis design, it achieves extremely high torque and power output within a limited installation space.
2. Extremely high efficiency and low-speed stability:
·The optimized plunger and port plate design ensures high volumetric and mechanical efficiency throughout the entire pressure and operating speed range.
·Excellent low-speed stability, capable of smooth start-up and non crawling operation at extremely low speeds, especially suitable for directly driving large wheels or rollers.
3. Durable and long-lasting:
·The heavy-duty roller bearing design can withstand extremely high radial and axial loads and has a long service life.
·The sturdy shell structure and high-quality component materials ensure the high reliability and long lifespan of the motor under harsh working conditions.
4. Wide applicability:
·The displacement range covers from 5.8 cm ³/rev to 500 cm ³/rev, providing multiple specifications to meet different torque and speed requirements.
·The working pressure is high, with a maximum continuous working pressure of 400 bar and a peak pressure of 450 bar.
5. Flexible configuration options:
·There are various forms of output terminals: providing spline shafts and flat key shafts for easy connection with various devices.
·Installation flange standards: comply with various international standards such as SAE, DIN, ISO, etc., with strong interchangeability.
·Optional integrated functions: such as flushing valve, parking brake, speed sensor, etc., to meet diverse system integration requirements.
6. Low noise operation:
·Precise machining and optimized flow pulsation characteristics ensure smooth motor operation with low noise levels.
3, Technical parameters (typical values)
Project parameter range
Displacement range 5.8-500 cm ³/rev
Rated working pressure up to 400 bar
Peak pressure up to 450 bar
The maximum speed depends on the displacement and can reach up to 6000 rpm (small displacement models)
Volume efficiency ≥ 96% (typical value)
Total efficiency ≥ 94% (typical value)
Installation interface SAE, DIN, ISO standard flange
Axial extension form spline, flat key
4, Application Fields
A2FM hydraulic motors are widely used in the following fields due to their excellent performance:
·Construction machinery: walking, rotating, and hoisting mechanisms for excavators, cranes, concrete pump trucks, rollers, and rotary drilling rigs.
·Agricultural machinery: walking drive for combine harvesters and large tractors.
·Mining equipment: underground loader, rock drilling trolley, conveyor belt drive.
·Marine engineering: deck machinery (such as anchors, winches), propellers, servos.
·Industrial applications: injection molding machines, metal die-casting machines, rubber machinery, coiling machines.
5, Optional Features and Accessories
To adapt to more complex applications, A2FM motors offer multiple options:
·Parking brake: an integrated multi disc brake used for safe parking and parking.
·Flush valve: used in closed circuits to help control oil temperature and maintain system cleanliness.
·Speed sensor: provides speed feedback signal for closed-loop speed control.
·Drain port: Different positions of drain ports can be selected for convenient pipeline layout.
